Tile & Plumbing Elevations
Whether you’ve already selected all your plumbing fixtures and tile, or you need help sourcing the perfect combination, my Tile & Plumbing Elevations service ensures every detail is perfectly placed before a single tile is set.
Sometimes the builder’s plumbing package is already chosen, and your tile is sitting in the garage ready to go. In that case, I work with what you’ve got—creating detailed, dimensioned elevation drawings so you (and your installer) can see exactly how it will look.
If you’re starting from scratch and want me to select everything for you, I offer a full sourcing package that includes finding your plumbing fixtures, choosing tile, grout colors, and creating a cohesive design plan.What You Get
Dimensioned tile and plumbing elevations for showers, tubs, and other wet areas.
Plumbing layout optimization—making sure valves, controls, and shower heads are in the right place for both function and comfort.
Fixture coordination—from thermostatic controls to transfer valves, we decide if you need multiple controls or a single integrated system.
Water temperature strategy—placing valves so you can turn the shower on and let the water warm up without stepping into the spray.
Tile layout planning—aligning grout lines with plumbing locations for a clean, intentional look.
Handedness considerations—right-handed or left-handed placement for handheld showers.
Shampoo niche design—dimensions, locations, and details so they’re both practical and beautiful.
Visuals for clarity—drawings that use your actual tile size (or traced mosaics) to show exact design intent.
How We Work Together
Review Selections — You send me your chosen fixtures and tile, or we begin the sourcing process if you’re starting fresh.
Layout & Placement — I create detailed elevations showing precise plumbing locations and tile layout.
Function & Flow Check — We walk through the drawings together, confirming everything from control height to niche placement.
Final Plans — You receive dimensioned drawings ready for your builder or installer, minimizing on-site guesswork.
Typical Timeline
Initial review and notes: 3–5 business days after receiving plans.
Meeting & feedback session: Within 1 week of plan delivery.
Final deliverables: 2–3 business days after revisions.
This process avoids costly rework and awkward surprises—like a valve that’s too high, grout lines that cut across a fixture, or a niche that’s just a little too short for your favorite shampoo bottles. Every decision is made intentionally so your tile and plumbing work together in harmony.
